8 Inch LCD 150cm IP65 Face Recognition Body Temperature Scanner
-
High Light
IP65 Face Recognition Body Temperature Scanner
,150cm Face Recognition Body Temperature Scanner
,800×1280 Face Recognition Infrared Thermometer
-
ApertureF2.4
-
Focusing Distance50-150cm
-
White BalanceAuto
-
Size8.0 Inch IPS LCD Screen
-
Resolution800×1280
-
CPURK3288 Quad-core (optional RK3399 Six-core, MSM8953 Eight-core)
-
StorageEMMC 8G
-
Audio2.5W / 4R Speakers
-
Serial Communication1 RS232 Serial Port
-
Relay Output1 Door Open Signal Output
-
WiegandOne Wiegand 26/34 Output, One Wiegand 26/34 Input
-
Upgrade ButtonSupport Uboot Upgrade Button
-
Wired Network1 RJ45 Ethernet Socket
-
Face LibraryUp To 30,000
-
UsageLaser Infrared Thermometer
-
Weight1.5kg
-
Response Time5s
-
Place of OriginChina
-
Brand NameGenvsion
-
CertificationCE FCC RoHS
-
Model NumberMG-080
-
Minimum Order Quantity1PCS
-
Price530
-
Packaging DetailsStandard export package
-
Delivery Time2-15 DAYS
-
Payment TermsMoneyGram, Western Union, D/A, L/C, D/P, T/T
-
Supply Ability1000PCS
8 Inch LCD 150cm IP65 Face Recognition Body Temperature Scanner
Washing hands conductive scanner for attendance and infrared lcd screen in 8 inch for face recognition and fever detector
Quick detail:
1.Welcome to get conductive kiosk of detection in face recognition and fever scanner from Shenzhen Mercedes Technology!
2.Face recognition for door access control and company attendance for face indentify.
3.Different stands avaiable for floor stands,desktop stands,children stands and customized sthands.
4.With internet connetor for wifi and software supply.
5.With international languages for choices.
Specification:
| Model | MG-08D | ||||
| Camera | Resolution | 200W pixel | |||
| Type | Binocular wide dynamic camera | ||||
| Focusing distance | 50-150cm | ||||
| White balance | automatic | ||||
| Screen | Size | 8.0inch IPS LCD | |||
| Resolution | 800×1280 | ||||
| Processor | CPU | RK3288 Quad core /RK3399 six core /MSM8953 eight core | |||
| Parts | Memory | EMMC 8G | |||
| Fill light | LED and Infrared double fill light | ||||
| Interface | Network module | Supports Ethernet,wireless(WIFI) | |||
| Audio | Support 2.5W/4R speaker | ||||
| USB port | 1 road USB OTG,１ road USB HOST standard A port | ||||
| Serial | 1 road RS232 Serial port | ||||
| Function | Relay output | 1 door open signal output | |||
| Wiegand interface | One Wiegand 26/34 output, one Wiegand 26/34 input | ||||
| Upgrade button | Support Uboot upgrade button | ||||
| Wired network | 1 RJ45 Ethernet socket | ||||
| Face Detection | Supports detection and tracking of multiple people at the same time | ||||
| Face library support | Up to 30,000 | ||||
| 1: N face recognition | Support | ||||
| 1: 1 face comparison | Support | ||||
| Stranger detection | Support | ||||
| Identify distance | Support | ||||
| UI interface configuration | Support | ||||
| Remote device upgrade | Support | ||||
| Device interface | Interfaces include device management, personnel / photo management, record query, etc. | ||||
| Deployment method | Support public cloud deployment, privatized deployment, LAN use, stand-alone use | ||||
| Infrared thermal imaging module | Human temperature detection | Support | |||
| Temperature detection distance | 1 Meter | ||||
| Temperature measurement accuracy | ≤ ±0.2℃ | ||||
| Temperature measurement range | 10℃~42℃ | ||||
| Thermal Field of View | 32 X 32 ℃ | ||||
| Visitors' temperature is normal and released directly | Support | ||||
| Body temperature over temperature alarm | Support (body temperature alarm value can be set) | ||||
| General parameters | Protection class | IP65, certain outdoor dustproof and waterproof function | |||
| Power | DC12V(±10%) | ||||
| Operating temperature | ﹣10℃~60℃ | ||||
| Storage temperature | -20℃~60℃ | ||||
| Power consumption | 13.5W(Max) | ||||
| Installation method | Gate bracket installation | ||||
| Equipment size | 238.24*128*25(mm) | ||||
| Weight | 1.45kg | ||||
