Safety face detector on the stations busy gate instruments kiosk facial warning scanner in office buildings and Malls
Quick details :
1 . Door facial digital detection kiosk management sensor faces lcd face scanner for schools , bus stations , official .
2 . High technology with facial express detection and infrared sensor detector of temperatures .
3 . Warning of scanning no contact electronic screen infrared digital slim measurement .
4 . Warning for IC card , school datas faces detector .
5 . Speak if no safety conductive measurement .
6 . Standard exports / exported licence for displayers , face detection.
Specification:
8 inch face recognition LCD display equipment development and production
Model | MG-08D | |
Camera | Resolution | 200W pixel |
Type | Binocular wide dynamic camera | |
Focusing distance | 50-150cm | |
White balance | automatic | |
Screen | Size | 8.0inch IPS LCD |
Resolution | 800×1280 | |
Processor | CPU | RK3288 Quad core /RK3399 six core /MSM8953 eight core |
Parts | Memory | EMMC 8G |
Fill light | LED and Infrared double fill light | |
Interface | Network module | Supports Ethernet,wireless(WIFI) |
Audio | Support 2.5W/4R speaker | |
USB port | 1 road USB OTG,1 road USB HOST standard A port | |
Serial | 1 road RS232 Serial port | |
Function | Relay output | 1 door open signal output |
Wiegand interface | One Wiegand 26/34 output, one Wiegand 26/34 input | |
Upgrade button | Support Uboot upgrade button | |
Wired network | 1 RJ45 Ethernet socket | |
Face Detection | Supports detection and tracking of multiple people at the same time | |
Face library support | Up to 30,000 | |
1: N face recognition | Support | |
1: 1 face comparison | Support | |
Stranger detection | Support | |
Identify distance | Support | |
UI interface configuration | Support | |
Remote device upgrade | Support | |
Device interface | Interfaces include device management, personnel / photo management, record query, etc. | |
Deployment method | Support public cloud deployment, privatized deployment, LAN use, stand-alone use | |
Infrared thermal imaging module | Human temperature detection | Support |
Temperature detection distance | 1 Meter | |
Temperature measurement accuracy | ≤ ±0.2℃ | |
Temperature measurement range | 10℃~42℃ | |
Thermal Field of View | 32 X 32 ℃ | |
Visitors' temperature is normal and released directly | Support | |
Body temperature over temperature alarm | Support (body temperature alarm value can be set) | |
General parameters | Protection class | IP65, certain outdoor dustproof and waterproof function |
Power | DC12V(±10%) | |
Operating temperature | ﹣10℃~60℃ | |
Storage temperature | -20℃~60℃ | |
Power consumption | 13.5W(Max) | |
Installation method | Gate bracket installation | |
Equipment size | 238.24*128*25(mm) | |
Weight | 1.45kg |
