8 Inch IPS Face Recognition Infrared Thermometer

8 Inch IPS Face Recognition Infrared Thermometer

  • High Light

    8 Inch Face Recognition Infrared Thermometer

    ,

    IPS lcd infrared thermometer

  • Resolution
    2 Million Pixels
  • Type
    Binocular Wide Dynamic Camera
  • Aperture
    F2.4
  • Focusing Distance
    50-150cm
  • White Balance
    Auto
  • Photo Flood Light
    LED And IR Dual Photo Flood Light
  • Size
    8.0 Inch IPS LCD Screen
  • Touch
    Not Supported (optional Support)
  • CPU
    RK3288 Quad-core (optional RK3399 Six-core, MSM8953 Eight-core)
  • Storage
    EMMC 8G
  • Place of Origin
    China
  • Brand Name
    genevision
  • Model Number
    MG-080
  • Minimum Order Quantity
    2 PCS
  • Price
    585
  • Packaging Details
    Standard export package
  • Delivery Time
    15-30 days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    1000pcs/Month

8 Inch IPS Face Recognition Infrared Thermometer

Door Face Detector with 8 inch Screen Electronic No False Binocular Face Recognition Passover Screen



Quick points:

1. Face control door access desktop and floor standing machine in stock.

2. Made from nice displayer screen for long time to use .

3. Which can be supplied with shopping mall,stations,bus stop,etc.

4. Have symbic best dynamic face recognition binocular sensor controls infrared sensor reflection version.

5. Face control by sensor facial detectors with door fence interface,usb,etc.

Specification:

Model MG-08D
Camera Resolution 200W pixel
Type Binocular wide dynamic camera
Focusing distance 50-150cm
White balance automatic
Screen Size 8.0inch IPS LCD
Resolution 800×1280
Processor CPU RK3288 Quad core /RK3399 six core /MSM8953 eight core
Parts Memory EMMC 8G
  Fill light LED and Infrared double fill light
Interface Network module Supports Ethernet,wireless(WIFI)
Audio Support 2.5W/4R speaker
USB port 1 road USB OTG,1 road USB HOST standard A port
Serial 1 road RS232 Serial port
Function Relay output 1 door open signal output
Wiegand interface One Wiegand 26/34 output, one Wiegand 26/34 input
Upgrade button Support Uboot upgrade button
Wired network 1 RJ45 Ethernet socket
Face Detection Supports detection and tracking of multiple people at the same time
Face library support Up to 30,000
1: N face recognition Support
1: 1 face comparison Support
Stranger detection Support
Identify distance Support
UI interface configuration Support
Remote device upgrade Support
Device interface Interfaces include device management, personnel / photo management, record query, etc.
Deployment method Support public cloud deployment, privatized deployment, LAN use, stand-alone use
Infrared thermal imaging module Human temperature detection Support
Temperature detection distance 1 Meter
Temperature measurement accuracy ≤ ±0.2
Temperature measurement range 10~42
Thermal Field of View 32 X 32
Visitors' temperature is normal and released directly Support
Body temperature over temperature alarm Support (body temperature alarm value can be set)
General parameters Protection class IP65, certain outdoor dustproof and waterproof function
Power DC12V(±10%)
Operating temperature 10~60
Storage temperature -20~60
Power consumption 13.5W(Max)
Installation method Gate bracket installation
Equipment size 238.24*128*25(mm)
Weight 1.45kg

Features:

1. Adopt 8-inch IPS full-view LCD display.
2. Industrial-grade appearance, waterproof and dustproof design, stable and reliable.
3. Support 3W face database. The 1: 1 comparison recognition rate is more than 99.7%, the 1: N comparison recognition rate is more than 96.7%@0.1% misrecognition rate, and the live detection accuracy rate is 98.3%@1% misrejection rate. Face recognition pass speed is less than 1 second.
4. Supports accurate face recognition and comparison while wearing a mask.
5, using industrial-grade binocular wide dynamic camera, infrared and LED double compensation at night.
6. Support optional Rockchip RK3288 quad-core processor, Rockchip RK3399 six-core processor and Qualcomm MSM8953 octa-core processor.
7. Support human body temperature detection, temperature display, 1-meter ultra-long body temperature detection, 0.2 ℃ error, support and automatic alarm for abnormal body temperature, second-level detection speed, and real-time export of attendance temperature measurement data.
8, support for ID card reader, fingerprint reader, IC card reader, two-dimensional code reader and other peripheral expansion.
9. Support system-level, APP offline-level, APP + background network-level API docking, complete documentation, and support secondary development.
