Bus Passengers Android 7.1 Digital Infrared Thermometer

Bus Passengers Android 7.1 Digital Infrared Thermometer

  • High Light

    digital ir infrared thermometer


    lcd infrared thermometer

  • Material
    Metal Case+tempered Glass Panel
  • Color
    Black And Silver
  • Stand
    Floor Standing Or Fixed On The Access
  • Software
  • Language
    Chinese And English
  • OS
  • Place of Origin
  • Brand Name
  • Certification
  • Model Number
  • Minimum Order Quantity
  • Packaging Details
    carton case and wooden case
  • Delivery Time
  • Payment Terms
    L/C, Western Union, T/T
  • Supply Ability

Bus Passengers Android 7.1 Digital Infrared Thermometer

Bus Passagers Temperature Alarm Infrared Thermometer Lcd Advertising Display Screen with Record the Face System


Item Description:

Smart Facial recognition & Check-in management system, with Rockchip RK3288/RK3399 high performance platform, dual industrial class camera and face recognition technology,and infrared human body temperature measurement module, is a high-performance, high reliability product., supporting 1:1 and 1:N face comparison and retrieval, mask recognition, human body temperature detection, high temperature warning, and Identity Card reader, fingerprint instrument and other peripheral extensions. It can be applied to access control and attendance for safe and efficient access control of personnel.

1. Use 8 Inch IPS LCD screen
2. Industrial grade, waterproof
3. Support face recording database of 30,000
4. Support face accurate detection and matching when people wearing mask
5. Use industrial grade two-eye dynammic camera
6. Has Rockchip RK3288 Quad-core CPU
7. Support human body temperature long distance detection of more than 1M, automatic alarm for abnormal temperature
8. Support various API connection for system, support secondary development


Panel Specification/Product Show
Resolution 1280*800 IPS panel
Display area 107.64(W)×172.224(H) mm
Brightness 200cd/m2
Number of Color 16.7M
Response time 8 (ms) approximately
Contrast 800:1
View angle 170°/170°(H/V)
Life Time > 50000 (hours)
Power Supply DC12V (±10%)
Power Consumption 14W
Camera 2.0Mpx, Binocular wide dynamic camera
Focus distance 50-150cm
White balance Automatic
LED flash LED and dual IR LED light compensation
Speaker 2.5W/4R
Face recognition Support several face detection together
Face recording database 30,000 at most
1: N face recognition Suport
1: 1 face comparison Suport
Stranger detection Suport
Identify distance configuration Support
UI interface configuration Support
Upgrade remotely Support
Display interface Interfaces include device management, personnel / photo management, record query, etc.
Deployment model Support public cloud deployment, privatized deployment, LAN use, stand-alone use
Temperature detection Support
Temperature detection distance 1 meter (optimal distance 0.5 meter)
Temperature measurement range ≤ ±0.5℃
Testing range 10℃~42℃
Thermal field of view 32 X 32℃
Visitors' temperature is normal and released directly Support
Abnormal temperature alarm Support (temperature alarm value can be set)
Waterproof IP65
Installation Gate machine, height can be adjusted
Photo Formats JPEG ,BMP ,GIF ,PNG
Audio Formats MP3,WAV,WMA
Shell Material Aluminum+Metal
Bare diemension 274.24*128*21.48(mm), N.W.: 1.45kg
Touch Type NO
Normal Working Temperature 0℃~60℃
Normal Storage Temperature -20℃~60℃
Packing list Machine * 1, power adapter * 1, manual * 1, certificate of conformity * 1
OSD Language English, Chinese, French, German, Italian, Spanish,Arabic etc.
Mainboard Hardware Configuration
CPU RK3288 Quadcore Cortex-A17 1.8GHz
Memory 8G
Internet connetcion Wifi, RJ45
System Android7.1
USB port OTG*1, USB HOST*1
RS232 1
Relay output 1 signal output for door openning
Wiggins interface 26/34 output*1, 26/34 input
Upgrade Support Uboot upgrade

 Bus Passengers Android 7.1 Digital Infrared Thermometer 0Bus Passengers Android 7.1 Digital Infrared Thermometer 1Bus Passengers Android 7.1 Digital Infrared Thermometer 2Bus Passengers Android 7.1 Digital Infrared Thermometer 3Bus Passengers Android 7.1 Digital Infrared Thermometer 4Bus Passengers Android 7.1 Digital Infrared Thermometer 5



Product Model MG-08D Camera Screen Processor Accessories Interface Resolution 200W Pixel Type Binocular Wide Dynamic Camera Focus Distance 50-150cm White Balance Auto Size 8.0 Inch IPS LCD Screen Resolution 800 × 1280 CPU RK3288 Quad Core / RK3399 Six Core / MSM8953 Eight-core local storage EMMC 8G fill light LED and infrared double fill light network module support Ethernet, wireless (WIFI) audio support 2.5W / 4R speaker USB interface 1 USB OTG, 1 USB HOST standard A port serial communication Interface: 1 RS232 serial port
Wiegand interface 1 Wiegand 26/34 output, Wiegand 26/34 input Wired network interface 1 RJ45 Ethernet socket Face database Support up to 30 thousand 1: 1 face comparison Support identification distance configuration Support device remote Upgrade support deployment method Support public cloud deployment, privatized deployment, LAN use, stand-alone temperature detection distance 1 meter Temperature measurement range 10 ℃ ~ 42 ℃ Visitor body temperature is normal direct release Support protection level IP65, certain outdoor dustproof and waterproof function working temperature ﹣10 ℃ ~ 60 ℃ Power consumption 13.5W (Max) Device size 238.24 * 128 * 25 (mm

In this special time,we need to control the person come in and out of the building or living area or school,will test the temperature and record the information.So we researched and produced this products,can be installed in the gate of the area. Test the temperature and record the information of all the people come in.

We lockdown for a long time ,but we will back to work at last. So many organiztion and management need a auto measure temperature machine,we did it. It's hot now,we can receive many inquiries from the customers.


There are 2 mode ,one is stranger mode,everyone can come in this mode.When someone come close to the machine,even waring mask,the infrared thermometer will scann him and measure his temperature,if he is over the normal temperature,it will alarm and will not open the gate.And all the information (the face and temperature) will be recorded in the system,you can check all the information in the background.


Another mode is the person were in record mode,in this mode,the stranger cann't come in,but they will be measured by the IR thermometer when come close. As the same,all the information will be recorded in the system.
