55 Inch LCD Video Wall Frameless 0.88mm 500cd Brithtness Gap 3x4 LG Panel
LCD video wall details
Manufactured under the strict ISO9001 quality control system, each factory machine reaches the international advanced level and meets the 3C standard;
Hardware architecture, software operating system, pure green version of the control software does not need to be installed; the interface is simple and the operation is extremely user-friendly;
The splicing unit adopts a modular design, which is easy for maintenance and board replacement; the modular structure is convenient for expansion;
Integrated multiple video signal source input interfaces;
Ultra-quiet dual fan cooling with humidity control
With aluminum alloy appearance, anti-glare and anti-eye impact design
LCD video wall splicing method
Full screen display --- the entire splicing screen displays an image horizontally or vertically
Single screen display --- each screen displays different images
Picture Roaming --- Through software, a signal image can be moved arbitrarily in the entire screen
Picture overlay --- through software, one signal can be superimposed on any other signal
Any combination display --- any number of signal units can display an image
LCD panel specification
| Brand | LG Display | Model | LD550DUN-TMA1 |
| Diagonal Size | 55 inch | Type | a-Si TFT-LCD , LCM |
| Pixel Format | 1920(RGB)×1080 [FHD] | Configuration | RGB Vertical Stripe |
| Active Area | 1209.6(H)×680.4(V) mm | Outline Dim. | 1210.51(H)×681.22(V) ×54.3(D) mm |
| Bezel Area(mm) | 0.88mm | Treatment | Antiglare (Haze 3%), Hard coating (2H) |
| Luminance | 700 cd/m² (Typ.) | Contrast Ratio | 1200 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Response | 8 (Typ.)(G to G) ms |
| Good View at | Symmetry | Work Mode | S-IPS, Normally Black, Transmissive |
| Color Depth | 1.06B 72% NTSC | Backlight | WLED , 50K hours , With LED Driver |
| Splicing Seam | 0.88mm | ||
|
Storage Temp.: -20 ~ 60 °C | ||
| Refresh Rate | 60Hz |
Our products are sold all over the world, you can rest assured.
