DID BOE 55inch LCD Video Wall 500nit Brightness Narrow Bezel 3.5mm

DID BOE 55inch LCD Video Wall 500nit Brightness Narrow Bezel 3.5mm

  • High Light

    55inch LCD Video Wall

    ,

    500nit Brightness LCD Video Wall

    ,

    3.5mm Narrow Bezel LCD Video Wall

  • Panel Size
    55'' DID Lcd Video Wall
  • Brightness
    500cd
  • Resolution
    HD 1920*1080
  • Install
    Wall Mounted
  • Espect Ratio
    1200:1
  • Material
    Aluminum Shell
  • Interface
    HDMI Output,USB, RJ45,VGA
  • Place of Origin
    Shenzhen China
  • Brand Name
    Genevision
  • Certification
    CE FCC CCC ROHS
  • Model Number
    MG-550
  • Minimum Order Quantity
    2pcs
  • Price
    $500-$700
  • Packaging Details
    Cartoon box with bubble then wooden case safe package
  • Delivery Time
    10-15 working days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    1000pcs/Month

DID BOE 55inch LCD Video Wall 500nit Brightness Narrow Bezel 3.5mm

55inch DID BOE LCD Video Wall 500nit Brightness Narrow Bezel 3.5mm

1. Use DID panel

The unique DID (Digital Information Display) panel technology has become the focus of attention in the display industry. The revolutionary breakthrough of DID panel lies in ultra-high brightness, ultra-high contrast, ultra-durability and ultra-narrow-edge applications, which solves the technical obstacles of liquid crystal display in public display and digital advertising signs. Generally speaking, the brightness of LCD screens used in televisions or computers is only 250 ~ 300cd / m2, and the brightness of LCD screens with DID panels is as high as 700cd / m2 and the contrast ratio is as high as 10000: 1, which is twice as high as that of traditional computer or TV LCD , Three times the average rear projection. Therefore, professional LCD monitors with DID panels are clearly visible even under strong outdoor light.

2. High brightness

Compared with TV and PC LCD screens, LCD splicing screens have higher brightness. The brightness of TV or PC LCD screen is generally only 450 ~ 500cd / ㎡, while the brightness of LCD LCD splicing screen can reach 700 cd / ㎡ (46 ″). 3. High-contrast DID LCD screen has a contrast ratio of 3000: 1 (46 ″), It is more than double than the traditional PC or TV LCD screen, and three times that of general rear projection.

3. Image processing technology

The LCD splicing screen can clearly reproduce low-pixel images in a Full HD display; de-interlacing technology to eliminate flicker; de-interlacing algorithm to eliminate "aliasing"; dynamic interpolation compensation, 3D comb filtering, 10-bit digital brightness and color Enhancement, automatic skin color correction, 3D motion compensation, non-linear scaling and other international leading technologies.

4. Better color saturation

The color saturation of ordinary CRT is only about 50%, and DID LCD can reach 92% high color saturation. This is due to the color calibration technology developed for the product. With this technology, in addition to color calibration for still images, Color calibration can also be performed on dynamic pictures, so as to ensure accurate and stable picture output.

5. A wider perspective

PVA (Patterned Vertical Alignment) technology is the "image vertical adjustment technology". With this technology, the viewing angle can reach more than 178 ° (horizontal and vertical).

6, better reliability

The ordinary LCD screen is designed for TV and PC monitors, and does not support continuous use day and night. The LCD splicing screen is designed for monitoring centers and exhibition centers, and supports continuous use 7x24 hours.

7, high viewing angle

Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle high enough to display vivid colors throughout the screen with virtually no distortion.

8, feature

1. Support 4K HD Play
2. Mobile/computer control
3. Screen Size: 43/46/49/55/65 inch (Option)
4. Ultra-narrow border: 0.88/1.8/3.5/5.5mm (Option)
5. Four installation methods : Cabinet / Floor standing / Front maintenance / Wall mount
6. Three external connections: splitter/matrix/processor


LCD Panel specification:

Application Details



Basic Info

Basic Info Panel Brand Panel Model MG-550
Diagonal Size 55" Model Alias
Panel Type a-Si TFT-LCD , LCM Storage Temp. -20 ~ 60 °C
Pixel Features Pixel Format 1920(RGB)×1080, FHD Dot Pitch 0.124×0.372 mm
Configuration RGB Vertical Stripe Pixel Pitch 0.372×0.372 mm
Mechanical Size outline Demension 1213*684*90mm Outline Dim. 1213*684*90mm
Outline Features Form Factor Flat Rectangle Orientation Landscape / Portrait
Aspect Ratio 16:9 (H:V) Videowall Seam 3.5 mm (Active to Active)
Holes & Brackets Side mounting holes, Rear mounting holes
Other Features Weight 13.5/14.2Kgs (Typ./Max.) Surface Antiglare (Haze 3%), Hard coating (2H)
Optical Details
Basic Information Brightness 500 cd/m² (Typ.) Contrast Ratio 4000:1 (Typ.) (Transmissive)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Optical Mode S-IPS, Normally Black, Transmissive
Viewing Direction Symmetry Response Time 8 (Typ.)(G to G) ms
Frame Frequency 60Hz
Reverse Scan No
Power Consumption 82.1W (Typ.)
Power supply AC 110V - 240V, 50/60HZ
Storage Temperature -7 to 65 Celsius degree
Normal Working Temperature 0 to 50 Celsius degree




DID BOE 55inch LCD Video Wall 500nit Brightness Narrow Bezel 3.5mm 0
DID BOE 55inch LCD Video Wall 500nit Brightness Narrow Bezel 3.5mm 1
DID BOE 55inch LCD Video Wall 500nit Brightness Narrow Bezel 3.5mm 2
