Floor Stand 55 Inch Video Wall 5x5 Controller 3.5mm Gap For Shopping Mall

Floor Stand 55 Inch Video Wall 5x5 Controller 3.5mm Gap For Shopping Mall

55-inch splicing screen LCD splicing curtain wall system is a combination of LCD splicing display unit, LCD splicing bracket, LCD splicing image processor, LCD splicing device and signal source. The LCD screens commonly used in the market today are 46-inch, 49-inch, 55-inch, and 65-inch LCD screens.

55-inch splicing screen product features:

1. LG original industrial-grade DID3.5mm patchwork LCD panel;

2, high-definition vision: 1920 * 1080P high-definition resolution, high brightness, high color gamut, high contrast, guarantee perfect display effect;

3. Using the latest 3D digital filtering and 3D digital noise reduction technology to better eliminate bright and noisy interference;

4. On the basis of the original frame noise reduction, the frame-to-frame noise reduction function has been added, and the analog high-definition IPS has greatly improved the image and wide dynamic functions;

5. Intelligent split screen technology: intelligent picture splicing, arbitrary combination of intelligent splicing, and more games through the software, bringing you a different feeling experience;

6, using a new ultra-wide viewing angle extension technology, high-definition image display in 178 ° viewing angle, no distortion, no distortion;

7. Simulated delivery: It can realize the transmission of mobile device signal source to the splicing screen for on-wall splicing display and other work;

8. The body is made of matt material, which brings you a different tactile experience with elegance and chic;

9. Silent cooling fan technology, good heat dissipation, long machine life, original handle, simpler installation;

10. Using IPS hard screen and 1080P image quality engine, the image is clear and sharp, and the details transition is smooth and smooth. Every place has been carefully carved to provide a better viewing angle experience;

11, built-in splicing technology, no need for external splicer;

12. Multiple splicing schemes are available. Horizontal, vertical, and irregular splicing schemes can meet your splicing needs.

Based on the flexible splicing method, it meets a variety of practical video interfaces, and the images are truly restored with stunning visual effects and grand momentum. Applicable to high-definition video requirements in all walks of life and various harsh light source environments. Products cover military, mining, electricity, airports, railways, public security, entertainment, libraries, museums, zoos, shopping malls and other display places, becoming a social civilization An indispensable communication tool in construction.

55-inch splicing screen product parameters:

1. Name of LCD splicing unit: LG 55-inch bilateral 3.5 mm (mm) stitching LCD splicing screen;

2.LCD splicing unit model: LTI550HN11

3. Panel type: 55 ”DID LCD Panel;

4, bilateral stitching: 3.5MM;

5. Product size: 1213.4mm × 684.2mm × 50.3mm (width × height × thickness);

6. Display size: 1209.6mm × 680.4mm (width × height);

7, display mode: S-IPS, normally black display, transmissive;

8. Surface treatment: matte (Haze44%);

7. Display ratio: 16: 9 golden ratio;

8, backlight type: WLED backlight;

9. Resolution: 1920 * 1080P;

10. Display color: 16.7M (8bit);

11. Brightness: 500 / 700cd / m2;

12. Contrast: 14000: 1;

13. Viewing angle: 178 °;

14. Response time: ≤6ms;

15. Field frequency: 50/60 / 70HZ;

16.Serial port control / RS232 input: 2 RS232-RJ45 (568B) inputs;

17. Serial port control / RS22 output: 2 RS232-RJ45 (568B) outputs;

18. Input signal: HDMI * 1, VGA1 (D-SUB) input, DVI * 1;

19. Composite video input: 1 BNC (BNC * 1) input;

20. Composite video output: 1 (BNC * 1) output;

21. 3D dynamic compensation: Yes;

22. 3D digital noise reduction: Yes;

23. Color system: PAL / NTSC / automatic identification;

24, compatible with HDTV input: 480P, 576P, 720P, 1080P;

23. Power supply: AC100-240V, 50 / 60HZ;

24. Power consumption: 160W;

25. Service life: 60,000 hours;

26. Menu language: Simplified Chinese, Traditional Chinese, English and other languages;

27.Standby power consumption: 1W;

28, cooling system: ultra-quiet dual fan cooling, with temperature control function;

29.Case material: rugged metal casing;

30.Working temperature: 0 ℃ -50 ℃;

31.Storage temperature: -20 ℃ -60 ℃;

32.Working / storage humidity: 20% -80%;

33.Installation system: cabinet / bracket / custom;

34.Installation methods: cabinet, wall mount, bracket, building block, embedded, mobile, etc .;

35, single screen weight: about 26KG;

36. Pixel pitch: 0.5303 * 0.5303;

37. Shell material: cold rolled steel plate / black;

38. Accessories: wall bracket, power cord, remote control, RS232 to RJ45 serial port connector, mounting screw M8 * 16, etc.
