Android Super Wide Stretched Bar LCD Monitor With Software

Android Super Wide Stretched Bar LCD Monitor With Software

  • High Light

    Super Wide Stretched Bar LCD Monitor

    ,

    23.1" Stretched Bar LCD Monitor

    ,

    400cd/m2 stretched bar display

  • Size
    23.1"LCD Panel
  • Active Display Area
    585.6(H) ×48.19(V)mm
  • Resolution
    1920(V)x158(H)
  • Brightness
    400cd/㎡
  • Contrast Ratio
    3O00:1
  • Display Color
    16.7M
  • Backlight
    WLED
  • Viewing Angles
    178°(H) X 178°(V)
  • Place of Origin
    China
  • Brand Name
    Genevision
  • Certification
    CE FCC ROSH CCC
  • Model Number
    MG-231
  • Minimum Order Quantity
    1pcs
  • Price
    $200-$300
  • Packaging Details
    Carton box with bubble first, then wooden case package
  • Delivery Time
    5-15 days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    10000pcs/Month

Android Super Wide Stretched Bar LCD Monitor With Software

Ultra wide stretched bar lcd monitor digital signage advertising display android wifi with software





Main board Spec.
CPU Rockchip PX30 Quad core ARM Cotex-A35
RAM 1G DDR3(1G/2G for optional(option)
ROM 8G EMMC(8G/16G/32G/64G EMMC for optionaloption)
Memory extension TF Card extension with the highest support for 64GB
System Android 8.1
Intetnet Support 2.4G WIFI connection
RTC real time clock Support timing on / off function
Interfaces 1*micro USB(OTG)
1*TF card,
1*Type-c(DC 12V input,Need to match with our company's special adapter for power supply)
machine specification
Operating voltage 100-240V(50/60Hz)
Power consumption ≤20W
Product size 597*60*15mm
Installation wall-mounted
material Metal materials
Net ≤0.7KG
Surface treatment Black metal paint
Environmental
Storage Environment Temperature:-20℃~60℃ Humidity:5%~95% Atmospheric Pressure:86kPa~104kPa
Working Environment Temperature:0℃~45℃ Humidity:10%~85% Atmospheric Pressure:86KPa~104KPa
Packing list
Admachine 1Pcs
OTG/Cable 1Pcs(OTG cable,micro USB to USB 2.0)
Adapeter 1Pcs (12V-2A)
Support for special requirements customization
