Interactive 450Cd/M2 350 Nits LCD Touch Screen Display

Interactive 450Cd/M2 350 Nits LCD Touch Screen Display

  • High Light

    350 Nits LCD Touch Screen Display


    450Cd/M2 LCD Touch Screen Display


    4K touch screen interactive whiteboard

  • Material
    Metal Case+tempered Glass Panel
  • Color
  • Resolution
  • Brightness
    350 Nits
  • System
    Windows And Android
  • Size
    65'' 75'' 86''
  • Place of Origin
  • Brand Name
  • Certification
  • Model Number
  • Minimum Order Quantity
  • Price
  • Packaging Details
    wooden case packed
  • Delivery Time
  • Payment Terms
    T/T, Western Union
  • Supply Ability

Interactive 450Cd/M2 350 Nits LCD Touch Screen Display

65'' 75'' 86'' Effecient for Conference High Sensitivity Interactive Whiteboard e-pen with OPS WIFI Wall Mount Bracket


Basic parameters

The most influential and intuitive basic parameters of whiteboard are:

1) Computer interface: international standard universal USB interface.

2) Resolution: resolution refers to the number of dots (or pixels) on each line. Points are usually represented along the horizontal and vertical edges of a screen or monitor; the higher the resolution, the clearer and smoother the picture is.

3) Calibration method: generally, the number of calibration points should be at least 2 points, which is more accurate positioning, will not produce drift, fast response.

4) Response speed: the faster the response speed, the closer to people's normal habits of operation, easy to use;

5) Touch precision: high precision, more sensitive to touch.



General Model No. 75GUG 85XUG DL100SUG
Panel size 75 inch 85 inch 100 inch
Display area 1650.24 ×928.26mm 1876.2 ×1057mm 2203 ×1239mm
Touch screen Optical touch, 10 points
Brightness 450 cd/m²
Color 8 bit/1.07 Billion
Working temp. +5 ~ +40℃
Life span ≥50000 hours
Power 100V-240VAC,50/60Hz
Power consumption 250W 350W 450W
Outlook Unit dimension 1725*1042.6*109.6mm 1961*1183.5*125.7mm 2297*1373.5*115.3mm
I/O HDMI in, RJ45*2, VGA in/out, AV in/out, earphone, USB*4, SD card slot, Mic in, SPDIF
Front panel Fingerprint lock, front panel cover
Android Android version 5.1
Chip MSD6A828
CPU/GPU CPU: Cortex A53*2 1.4GHz; GPU: Mail450MP4(4+2) 600MHZ
Memory RAM 2G DDR3, flash 4G
SD card Support MAX 128GB SD card
Windows OS Win7/8/10
CPU IntelCore I5 7500, 4G+128G (IntelCore I7 7700 is optional)
E-pen Connection Blue tooth
Writing 2048 grade pressure probe
Color changing 7 colors to choose, with indicator ligt
Shortcut key support self-defined shorcut key for play, turn page, clean...
Notes Office notes, annotation will be saved in original files.
Optional Camera 5MP resolution
Micro phone High sensitivity, pick sound in 5~10 meters
Mirroring Mirroring multiple device
Packing Packing list Interactive white board*1, remote control*1, power cable*1, e-pen*1, WIFI attena *3, OPS PC*1, wall mounting brakets, User manul*1, Warranty card*1
Packing dimension 1870*1150*220mm 2110*1315*240mm 2500*1630*440mm

Interactive 450Cd/M2 350 Nits LCD Touch Screen Display 0Interactive 450Cd/M2 350 Nits LCD Touch Screen Display 1Interactive 450Cd/M2 350 Nits LCD Touch Screen Display 2Interactive 450Cd/M2 350 Nits LCD Touch Screen Display 3Interactive 450Cd/M2 350 Nits LCD Touch Screen Display 4

Interactive electronic whiteboard is a kind of human-computer interactive electronic display platform which integrates computer technology, information technology, electronic technology and many other modern science and technology technologies. It can make the pictures on the computer display on the whiteboard, through the operation of the electronic whiteboard, it can directly control the computer, writing, annotation, eraser, painting, preview, interaction and many other functions, to a large extent, it is convenient for teachers' teaching and students' learning, and plays an important role in teaching activities. The following is a detailed introduction to the role of interactive whiteboard.
