Wall Mounted 19 Inch Subway Stretched Bar LCD

Wall Mounted 19 Inch Subway Stretched Bar LCD

  • High Light

    Subway Stretched Bar LCD


    300cd/m2 Stretched Bar LCD


    WLED backlight stretched bar display

  • Response Time
  • Type
    Ultra Wide Bar Stretched Lcd Refurbished Monitor
  • Input Voltage
  • Application
  • Brightness
  • Viewing Angle
    178 /178
  • Pixel Pitch
  • Max Resolution
  • Color
  • Warranty
    1 Year
  • Installation
    Wall Mounted/Embedded
  • After-sales Service Provided
    Online Support
  • Material
    Metal Case + Toughened Glass Panel
  • Size
  • Place of Origin
  • Brand Name
  • Certification
  • Model Number
  • Minimum Order Quantity
  • Price
  • Packaging Details
    Standard export package wooden case
  • Delivery Time
    2-15 DAYS
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability

Wall Mounted 19 Inch Subway Stretched Bar LCD

19inch wall mounted intelligent HD advertising machine bar screen LCD poster network screen subway shopping mall screen

Quick details:


1.It supports 1920x360 resolution of pictures and videos and text information release, clock support and multi split screen display.


2.According to the schedule management, the publishing content schedule can be divided into time period, day, week, month and


rotation; it can be displayed in single terminal or in groups


3.Support network access, terminal monitoring: download programs and server to terminal commands and execution status visualization.


4.It supports the continuous transmission of network interruption, the monitoring of terminal operation status, and the support of statistical reports;


5.Free segmentation of screen area: random combination of video, picture, subtitle, clock, weather forecast and network data source, etc


6.Player management: support system startup, shutdown, restart; support software remote upgrade


1. Supermarket shelf display field (shelf bar screen)


It is a trend for high-end supermarkets to display product information by taking advantage of the long and thin strip screen.

2. Advertising media


With its unique advantages, bar screen is gradually replacing the traditional billboards and light boxes, becoming a new force

in the advertising media industry.


Traditional advertising can only play pictures, while the bar LCD screen perfectly combines pictures, video, text and sound, and

has the advantages of high resolution, high brightness and high color gamut.

3. Intelligent transportation display field

It can be used as an indoor station announcement screen and a taxi roof screen in the subway and bus display, taxi top, subway

carriage, comprehensive display of vehicle arrival information and other multimedia information.

, props and children's toys

4. As a cool "big sword" in movie props, or applied to the field of children's toys, it may be very popular.


Size 19"LCD Panel
Active display area 476.64(H) × 89.37(V)mm
Resolution 1920(V)x360(H)
Brightness 300cd/㎡
Contrast ratio 1200:1
Display color 16.7M
Backlight WLED
Viewing angles 178°(H) X 178°(V)
Response time 30ms
Lifespan 30000 hours
Main board Spec.
CPU Rockchip PX30 Quad core ARM Cotex-A35
RAM 1G DDR3(1G/2G for optional)
ROM 8G EMMC(8G/16G/32G/64G EMMC for optional)
Memory extension TF Card extension with the highest support for 64GB
System Android 8.1
Intetnet Support 2.4G WIFI connection
RTC real time clock Support timing on / off function
Interfaces 1*micro USB(OTG),1*TF card,1*Type-c(DC 12V;DC 12V input,Need to match with our company's special adapter for power supply)
Optional 4G module
speak 8Ω1W*1
Support for special requirements customization
