32'' Usb Rear Projection Multi Touch Foil For Education / Table Mordern Conference

32'' Usb Rear Projection Multi Touch Foil For Education / Table Mordern Conference

  • High Light

    capacitive touch foil

    ,

    touch screen film

  • Place Of Origin
    Guangdong, China
  • Format
    16:9
  • Portable
    Yes
  • Lift Time
    7-9 Years
  • Connect Port
    RS232 Or USB
  • Respond Speed
    0.01s-0.05s According To The Thickness Of Glass
  • SKU
    In Stock
  • Warranty
    2 Years
  • Place of Origin
    China mainland
  • Brand Name
    Genevision
  • Certification
    CE, ROHS, FCC
  • Model Number
    MTR-320
  • Minimum Order Quantity
    1 pc
  • Price
    USB 137 per set
  • Packaging Details
    carton tubes
  • Delivery Time
    5-7 days
  • Payment Terms
    L/C, T/T, Western Union
  • Supply Ability
    3000 sets per month

32'' Usb Rear Projection Multi Touch Foil For Education / Table Mordern Conference





32'' Usb Rear Projection Multi Touch Foil For Education / Table Mordern Conference





Quick details :



The Interactive Touch Foil Features
Safety and robust
Anti­scratch, laminate on the back of
Waterproof, dust­proof, bullet­proof,
No expose components, safety.
No mechanical components with long life
Industrial temperature range: -20 °C to +

Art and Sci­Fi
High transparency ≥93%, glass­level transparency
No bezel of touch area
Thin and light, the sensor thickness only 0.17mm
Thru­glass touch, the maximum thickness of glass can reach 20mm.
Only hands valid, no touch action of metal, plastic, and so on.

Excellent experience
Zero pressure touch, even with glove.
Mouse function with Zoom in/out and rotation.
2 points Multi­touch, Support TUIO & Win Native
Precise touch & real­time response

Advanced features
Low power consumption, the maximu consumption is only 0.5w
Flexible, could be applied to curve surface screen
The film sensor could be laminated on any smooth non­metallic flat
Various size from 17" to 100", lowest cost customization.

aminate on the back of glass
proof, Acid­proof
long life
0 °C to +80 °C level
Thin and light, the sensor thickness only 0.17mm
glass touch, the maximum thickness of glass
nly hands valid, no touch action of metal, plastic,
Zero pressure touch, even with glove.
Mouse function with Zoom in/out and rotation.
touch, Support TUIO & Win Native



specification :

Detection Method: Projected Capacitance technology using horizontal vertical wires
Screen Sizes: From: 17" To 120" . Available in 4: 3 & 16: 9 format.
Position accuracy: Approximately 3 mm absolute, 1 mm relative. No drift
Alignment: Software drivers provide a calibration facility
Sensitivity: Adjustable by software. Can be programmed for different thickness of glass and even use with gloved hands. Functions with non-mertalise, single construction glass 16mm thick.
Speed of response: Depends upon glass thickness. Typically 50 to 100ms.
Output: RS232C communications to a 9 pin D female or USB Port
Software Compatibility: Windows XP & Vista. Windows7 windows8 Android,Linux,MOC
Temperature range: Better than -10 to +70
Humidity Controller: 0% to 95%. Unaffected by condensation
Light Transmission: Depend upon glass thickness, typically better than 95%



Picture show :



32'' Usb Rear Projection Multi Touch Foil For Education / Table Mordern Conference 0



32'' Usb Rear Projection Multi Touch Foil For Education / Table Mordern Conference 1

32'' Usb Rear Projection Multi Touch Foil For Education / Table Mordern Conference 2



Packing:
1-2 Pcs Sample Box:56*41*8cm(Size Under 19inch)
1-2 Pcs Sample Box:63*41*8cm(Size 19inch-23.6inch)
10 Pcs Order Box:57*49*36cm(Standard Touch Screen Size 15-19 inch Box)
Contact us for other touch screen box size.

Delivery time:
Standard Dustproof Sample order 1-2 Days,Vandal proof/Anti-Glare type 2-4 Days.
100 Pcs 7 Days, 500 Pcs 20 Days,More than 500 Pcs Order,Contact us for detail delivery time.
